PATIENT BED (FOUR MOTORS)

Product Code : TM-D 4056

TECHNICAL DOCUMENT

Product Functions

- • Height adjustment. (motor)
- • Backrest adjustment. (motor)
- • Thigh rest adjustment. (motor)
- • Footrest. (manuel)
- • Auto-regression system.
- • Trendelenburg and reverse trendelenburg (motor).
- • Handset control.
- • ABS mattress platform. (detachable)
- • ABS head and foot boards. (detachable)
- • ABS Side Rails.
- • Angle indicator. (backrest,trendelenburg)
- • IV pole. (height adjustable)
- • Accessories holders.
- • Castors two with break.
- • Protective corner bumpers.
- • Electrostatic powder coated frame. (RAL 7035)
Overall Dimensions:

1070 x 2030 mm

Bed Platform:

900 x 1900 mm

Bed Height Adjustment:

440 - 750 mm

Maximum Back Angle:

70°

Maximum Knee Angle:

40°

Trendelenburg / Reverse Trendelenburg:

+ 12 ° / - 12 °

Autocontour (back - knee):

75 – 50 mm

Side Rail Height:

380 mm

Headboard Height:

435 mm

Under Bed Clearance:

160 mm

Wheels:

125 mm

Safe Working Load:

150 mm

Carrying (Loading) Capacity:

300 kg
- • Weight scale system.
- • Bed length extension.
- • Battery.
- • X-Ray cassette holder.(Backrest)
- • Manuel CPR at backrest.
- • Integrated side rail controls.
- • Handset control with magnetic lock.
- • Orthopedics traction frame.
- • Lifting Pole.
- • Nurse control.
- • Central lock castors.
